Intel® Socket 1150 for 4th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
* 有關支援的 CPU 型號資訊，請參閱www.asus.com 網站內容。
支援 Intel® Turbo Boost 技術2.0
Supports Intel® 22 nm CPU
* The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.

Intel® H81

2 x DIMM, Max. 16GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
* 是否支援 Hyper DIMM 需視個別 CPU 的實體特性而定。
* 有關記憶體合格廠商清單（QVL）的相關資訊，請參閱 www.asus.com 網站或本使用手冊。
* Due to Intel® chipset limitation, DDR3 1600 MHz and higher memory modules on XMP mode will run at the maximum transfer rate of DDR3 1600 Mhz.

Integrated Graphics Processor
支援多 VGA 輸出 : DVI/RGB ports
– 支援 DVI 最大解析度1920 x 1200 @ 60 Hz
– 支援 RGB 最大解析度1920 x 1200 @ 60 Hz
最大共享記憶體1024 MB
Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™

1 x PCIe x16
2 x PCIe 2.0 x1

Intel® H81 chipset :
2 x SATA 6Gb/s port(s), yellow
2 x SATA 3Gb/s port(s), dark brown,
Supports Intel® Rapid Start Technology, Intel® Smart Connect Technology *1

Realtek® 8111G, 1 x Gigabit 區域網路控制器

Realtek® ALC887 8通道 高傳真音效 CODEC*2
– 支援 : Jack-detection, Front Panel Jack-retasking

Intel® H81 chipset :
2 x USB 3.1 Gen 1 port(s) (2 at back panel, blue)
Intel® H81 chipset :
6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)

ASUS EPU :
– EPU
華碩獨家功能 :
– GPU Boost
– AI Suite 3
– Ai Charger
– Anti-Surge
– ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
– Network iControl
– USB 3.0 Boost
– Disk Unlocker
華碩靜音散熱解決方案 :
– Stylish Fanless Design Heat-sink solution
– ASUS Fan Xpert
ASUS EZ DIY :
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 2
ASUS Q-Design :
– ASUS Q-Slot

Windows® 8
Windows 7

1 x PS/2 keyboard (purple)
1 x PS/2 mouse (green)
1 x DVI
1 x D-Sub
1 x LAN (RJ45) 連接埠
2 x USB 3.1 Gen 1 (blue)
2 x USB 2.0
3 x 音訊插孔

2 x USB 2.0 接頭支援額外的 4 USB 2.0 連接埠
2 x SATA 6Gb/s 接頭
2 x SATA 3Gb/s 接頭
1 x CPU 風扇接頭(1 x 4 -pin)
1 x 機殼風扇接頭 (1 x 4 -pin)
1 x S/PDIF 輸出接頭
1 x 24-pin EATX 電源接頭
1 x 4-pin ATX 12V 電源接頭
1 x 前面板音訊接頭 (AAFP)
1 x Front panel connector(s)
1 x Internal speaker connector(s)
1 x Clear CMOS jumper(s)

使用者手冊
2 x Serial ATA 6.0Gb/s 纜線
I/O Shield

64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information

WfM 2.0, DMI 2.0, WOL by PME, PXE

Drivers
ASUS Utilities
EZ Update
Anti-Virus Software (OEM Version)

uATX 主機板尺寸
8.9 inch x 6.9 inch ( 22.6 cm x 17.5 cm )

*1-1:Due to the limitation of the Intel® H81chipset, Intel® Rapid Start Technology can be configured only from the BIOS Setup program.
*1-2:These functions will work depending on the CPU installed.
*2:Use a chassis with HD audio module in the front panel to support an 8-channel audio output.
