AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics 處理器

*有關支援的 CPU 型號資訊，請參閱 tw.asus.com 網站內容。

AMD X570

4 x DIMM, 最高可支援到128GB, DDR4 MHz 無緩衝區 記憶體 *
3rd Gen AMD Ryzen™ Processors
雙通道 記憶體架構
*有關記憶體合格廠商清單（QVL）的相關資訊，請參閱 www.asus.com 網站或本使用手冊。
2nd Gen AMD Ryzen™ Processors
4 x DIMM, Max. 128GB, DDR4 MHz 無緩衝區 Memory *
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
4 x DIMM, Max. 128GB, DDR4 MHz 無緩衝區 Memory

Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
支援多 VGA 輸出 : HDMI/DisplayPort 連接埠
– Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz
– Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz

3rd and 2nd Gen AMD Ryzen™ Processors
Supports NVIDIA® 2-Way SLI® Technology
支援 AMD 3-Way CrossFireX™ 技術
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
Supports AMD 2-Way CrossFireX™ Technology

3rd Gen AMD Ryzen™ Processors
2 x PCIe 4.0 x16 (x16 or dual x8)
2 x PCIe 4.0 x1
2nd Gen AMD Ryzen™ Processors
2 x PCIe 3.0 x16 (x16 or dual x8)
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
1 x PCIe 3.0 x16 (x8 mode)
AMD X570 chipset
1 x PCIe 4.0 x16 (max at x4 mode) *1

3rd Gen AMD Ryzen™ Processors :
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support
AMD X570 chipset :
1 x M.2 x4 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support
8 x SATA 6Gb/s埠,
支援Raid 0, 1, 10

Intel® I211-AT, 1 x Gigabit 區域網路控制器
Realtek® RTL8125-CG 2.5G LAN
Anti-surge LANGuard
ROG GameFirst Technology

2 x 2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) with MU-MIMO supports dual frequency band 2.4/5GHz

Bluetooth® 5.0

SupremeFX 8 通道 高傳真音效 CODEC S1220A
– Dual OP Amplifiers
– 支援 : 插頭偵測, 多路音頻輸出輸入, 前面板插孔指定功能
– Impedance sense for front and rear headphone outputs
– High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
– SupremeFX Shielding Technology
– Supports up to 32-Bit/192kHz playback *2
Audio Feature :
– 光纖 S/PDIF 輸出埠位於背板
– Sonic Radar III
– Sonic Studio III + Sonic Studio Link

3rd Gen AMD Ryzen™ Processors :
4 x USB 3.2 Gen 2 連接埠 (4 位於背板, )
2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
4 x USB 3.2 Gen 1 連接埠
AMD X570 chipset :
1 x USB 3.2 Gen 2 front panel connector 連接埠
AMD X570 chipset :
4 x USB 3.2 Gen 2 連接埠 (4 位於背板, , 3 x Type-A+1 x Type-C)
AMD X570 chipset :
2 x USB 3.2 Gen 1 連接埠 (2 位於主機板中)
AMD X570 chipset :
4 x USB 2.0 連接埠 (4 位於主機板中)

ROG Exclusive Software
– RAMCache III
– CPU-Z
– GameFirst V
– Sonic Studio III + Sonic Studio Link
– Sonic Radar III
– Overwolf

華碩 EPU :
– EPU
5-Way Optimization by Dual Intelligent Processors 5
– Whole system optimization with a single click! 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo App together, providing better CPU performance, efficient power saving, precise digital power control, whole system cooling and even tailor your own app usages.
TPU
– Auto Tuning, TurboV, GPU Boost
Gamer’s Guardian:
– DRAM Overcurrent Protection
– Stainless Steel Back I/O
– Highly Durable Components
– DIGI+ VRM
– SafeSlot
– ESD Guards on LAN, Audio,and USB ports
華碩獨家功能 :
– USB BIOS Flashback™
– AI Suite 3
– Ai Charger
– ASUS NODE : hardware control interface
– BIOS Flashback™ Button
華碩 EZ DIY :
– 華碩 CrashFree BIOS 3
– 華碩 EZ Flash 3
華碩 Q-Design :
– 華碩 Q-LED (CPU, DRAM, VGA, Boot Device LED)
– 華碩 Q-Code
– 華碩 Q-Slot
– 華碩 Q-DIMM
AURA :
– Aura Lighting Control
– Addressable Gen 2 Header
Gaming Aesthetics :
– AURA-RGB Lighting

1 x DisplayPort
1 x HDMI
1 x 光纖 S/PDIF 輸出
5 x 音訊插孔
5 x USB 3.1 Gen 1 Type-A
8 x USB 2.0
1 x Anti-surge 2.5G LAN (RJ45) port
1 x USB BIOS Flashback™ Button(s)
1 x ASUS Wi-Fi Module
7 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A)
1 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-C)
Anti-surge LAN (RJ45) port

2 x USB 2.0 接頭支援額外的 4 USB 2.0 連接埠
1 x PCH_FAN
8 x SATA 6Gb/s 接頭
1 x CPU 風扇接頭
2 x 機殼風扇接頭
1 x AAFP connector
1 x 24-pin EATX 電源接頭
1 x 8-pin ATX 12V 電源接頭
2 x Aura RGB Strip Header(s)
1 x 4-pin ATX 12V 電源接頭
2 x Addressable Gen 2 header(s)
1 x 前面板音訊接頭 (AAFP)
1 x 熱感測器接頭
2 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support
1 x SPI TPM header
1 x Clear CMOS 跳線
1 x CPU OPT Fan connector(s)
1 x AIO_PUMP connector
1 x W_PUMP+ connector
1 x Node Connector(s)
1 x System panel connector
1 x T_Sensor Connector
1 x M.2 Fan Header
1 x USB 3.2 Gen 2 (up to 10Gbps) connector
1 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports

使用者手冊
4 x Serial ATA 6.0Gb/s 纜線
1 x 束線帶
1 x M.2 Screw Package
1 x Supporting DVD
1 x Strix door hanger
1 x ROG Strix stickers
1 x Wi-Fi Antenna(s)
1 x Extension Cable for RGB strips (80 cm)
1 x Extension cable for Addressable LED
1 x Thermistor cable(s)
1 x ROG Thank you card

256 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.2, ACPI 6.2.

WOL, PXE

Overwolf
Anti-virus software (OEM version)
WinRAR

Windows® 10 64-bit

ATX 主機板尺寸
12 吋 x 9.6 吋 ( 30.5 公分 x 24.4 公分 )

*1 PCIeX16_3 slot shares bandwidth with PCIeX1_2.
*2 Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
