Build in AMD AM4 Socket 3rd Gen AMD Ryzen™ 處理器 *

*有關支援的 CPU 型號資訊，請參閱 tw.asus.com 網站內容。

AMD B550

4 x DIMM, 最高可支援到128GB, DDR4 2933/2800/2666/2400/2133 MHz 非ECC, 無緩衝區 記憶體 *
雙通道 記憶體架構
支援 Intel® Extreme Memory Profile (XMP)
OptiMem
* 第 10 代 Intel® Core™ i9/i7 CPU 原生支援 2933/2800/2666/2400/2133，記憶體 QVL (合格廠商清單)，請參見 www.asus.com/tw。

1 x DisplayPort 1.2
1 x HDMI 2.1(4K@60HZ)

Supports AMD 2-Way CrossFireX Technology

3rd Gen AMD Ryzen™ Processors
1 x PCIe 4.0 x16 (x16 mode)
AMD B550 Chipset
1 x PCIe 3.0 x16 (x4 mode) *1
1 x PCIe 3.0 x1 *1
* Support PCIe bifurcation for RAID on CPU function.

3rd Gen AMD Ryzen™ Processors :
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
總共支援 2 x M.2 插槽和 4 x SATA 6Gb/s 連接埠
AMD B550 Chipset :
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support
4 x SATA 6Gb/s埠,
支援Raid 0, 1, 10

Realtek RTL8125B 2.5Gb Ethernet
TUF LANGuard

Intel® Wi-Fi 6 AX200
2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) 支援 1024QAM/OFDMA/MU-MIMO 支援最高 2.4Gbps 的最大資料速率
最高支援2.4Gbps的最大數據速率
支援雙頻 2.4/5 GHz
支援通道頻寬：HT20/HT40/HT80/HT160
Supports PCIe interface

藍牙 v5.1*
*BT 5.1 功能將在 Windows 10 build 19041 以上版本提供。

Realtek ALC S1200A 7.1 Surround Sound 高傳真音效 CODEC (Intel® Core™第10代處理器 選購)
– 支援 : Jack-detection, 插頭偵測, 多路音頻輸出輸入, 前面板插孔指定功能
音訊特色 :
– 光纖 S/PDIF 輸出埠位於背板
– Exclusive DTS Custom for GAMING Headsets.
– 音訊外蓋
– Audio Shielding
– Dedicated audio PCB layers
– 優質的日本音訊電容

背面 USB 連接埠 ( 共 8 個 )
2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C™)
4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
2 x USB 2.0 port(s)(2 x Type-A)
正面 USB 連接埠 ( 共 6 個 )
2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
4 x USB 2.0 port(s)(4 x Type-A)

ASUS Exclusive Software
Armoury Crate
– Aura Creator
– Aura Sync
– AI Noise Cancelling Microphone
AI Suite 3
– Performance And Power Saving Utility
TurboV EVO
EPU
Digi+ VRM
Fan Xpert 2+
– EZ update
TUF GAMING CPU-Z
AI Charger
ASUS Turbo LAN
DAEMON Tools
DTS Custom for GAMING Headsets
Norton Anti-virus software (Free Trial for 60 days)
WinRAR
UEFI BIOS
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode

ASUS TUF PROTECTION
– ASUS DIGI+ VRM (Digital power design with Dr. MOS)
– ASUS Enhanced DRAM Overcurrent Protection
– ASUS ESD Guards
– TUF LANGuard
– ASUS Overvoltage Protection
– ASUS SafeSlot
– ASUS Stainless-Steel Back I/O
ASUS Q-Design
– ASUS Q-DIMM
– ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
– ASUS Q-Slot
ASUS Thermal Solution
– Aluminum M.2 heatsink
ASUS EZ DIY
– BIOS FlashBack™ button
– BIOS FlashBack™ LED
– Procool
AURA Sync
– Standard RGB headers
– Addressable Gen 2 RGB header

1 x PS/2 鍵盤/滑鼠連接埠
1 x DisplayPort
1 x HDMI
1 x 光纖 S/PDIF 輸出
5 x 音訊插孔
1 x LAN (2.5G) port(s)
2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C™)
4 x USB 3.2 Gen 1 (藍色) Type-A
2 x USB 2.0 (Intel® Core™第10代處理器 選購)
1 x USB BIOS Flashback™ Button(s)
1 x ASUS Wi-Fi Module

2 x USB 2.0 接頭支援額外的 4 USB 2.0 連接埠
4 x SATA 6Gb/s 接頭
1 x CPU OPT Fan connector(s)
1 x CPU 風扇接頭
2 x 機殼風扇接頭
1 x 24-pin EATX 電源接頭
1 x 前面板音訊接頭 (AAFP)
2 x Aura RGB Strip Headers
1 x Addressable Gen 2 header(s)
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 4.0 x 4 mode)
1 x Clear CMOS 跳線
1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x SPI TPM header
1 x 8-pin EATX 12V Power connectors
1 x System panel connector
1 x COM port header
1 x Speaker connector

使用者手冊
I/O 擋板
2 x Serial ATA 6.0Gb/s 纜線
1 x TUF Certification 卡
1 x Supporting DVD
1 x TUF Gaming Sticker
1 x M.2 SSD screw package(s)
1 x M.2 Rubber Package(s)

256 Mb Flash ROM, UEFI AMI BIOS

WOL by PXE

Windows® 10 64-bit

mATX 主機板尺寸
9.6 吋 x 9.6 吋 ( 24.4 公分 x 24.4 公分 )

*1 PCIEX16_2 will run x2 mode when PCIEX1 is used.
