AMD AM4 Socket AMD Ryzen™ 2nd Generation/3rd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics 處理器

AMD X570

4 x DIMM, 最高可支援到128GB, DDR4 MHz 無緩衝區 記憶體
3rd Gen AMD Ryzen™ Processors
雙通道 記憶體架構
*有關記憶體合格廠商清單（QVL）的相關資訊，請參閱 www.asus.com 網站或本使用手冊。
ECC Memory (ECC mode) support varies by CPU.
2nd Gen AMD Ryzen™ Processors
4 x DIMM, Max. 128GB, DDR4 MHz 無緩衝區 Memory
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
4 x DIMM, Max. 128GB, DDR4 MHz 無緩衝區 Memory

Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
支援多 VGA 輸出 : HDMI/DisplayPort 連接埠
– 支援 DisplayPort 最大解析度 4096 x 2160 @ 60 Hz
– Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz

3rd and 2nd Gen AMD Ryzen™ Processors
AMD Ryzen™ 2nd Generation/Ryzen™ 1st Generation Processors
支援 AMD CrossFireX™ 技術

3rd Gen AMD Ryzen™ Processors
1 x PCIe 4.0 x16 (x16 mode)
2 x PCIe 4.0 x1
2nd Gen AMD Ryzen™ Processors
1 x PCIe 3.0 x16 (x16 mode)
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
1 x PCIe 3.0/2.0 x16 (x8 mode)
AMD X570 chipset
1 x PCIe 4.0 x16 (max at x4 mode)

3rd Gen AMD Ryzen™ Processors :
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
2nd Gen AMD Ryzen™ Processors :
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support
AMD X570 chipset :
1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
8 x SATA 6Gb/s埠
支援Raid 0, 1, 10

Realtek® L8200A
ASUS Turbo LAN Utility
TUF LANGuard

Intel® Wireless-AC 9260
Wi-Fi 802.11a/b/g/n/ac
Supports dual band frequency 2.4/5 GHz
Supports MU-MIMO
Supports channel bandwidth: HT20/HT40/HT80/HT160

Bluetooth® 5.0

Realtek® ALC S1200A 8 通道 高傳真音效 CODEC
Audio Feature :
– Exclusive DTS Custom for GAMING Headsets.
– Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
– Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
– Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
– Audio Cover: Effective shielding preserves the integrity of audio signals to ensure best quality.

3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
4 x USB 3.2 Gen 1 連接埠 (4 位於背板, )
AMD X570 chipset :
3 x USB 3.2 Gen 2 連接埠 (3 位於背板, , 2 x Type-A+1 x USB Type-C™)
AMD X570 chipset :
2 x USB 3.2 Gen 1 連接埠 (2 位於主機板中)
AMD X570 chipset :
4 x USB 2.0 連接埠 (4 位於主機板中)

ASUS TUF PROTECTION
– ASUS SafeSlot: Protect your graphics card Investment
– ASUS ESD Guard: Enhanced ESD protection
– ASUS Overvoltage Protection: World-class circuit-protecting power design
– ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
– ASUS DIGI+ VRM: Precision control for stable power
– ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
華碩獨家功能 :
– AI Suite 3
– Ai Charger
華碩靜音散熱解決方案 :
– Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan, PCH and M.2 Heatsink
– ASUS Fan Xpert 4
華碩 EZ DIY :
– 華碩 CrashFree BIOS 3
– 華碩 EZ Flash 3
– ASUS UEFI BIOS EZ Mode
華碩 Q-Design :
– 華碩 Q-LED (CPU, DRAM, VGA, Boot Device LED)
– 華碩 Q-Slot
– 華碩 Q-DIMM
AURA :
– Aura Lighting Control
– Aura RGB Strip Headers
– Addressable Gen 2 Header
DIY Friendly Design
– Procool
– SafeSlot
– Digi+ VRM
– Highly Durable components
– ESD Guards

1 x PS/2 鍵盤/滑鼠連接埠
1 x DisplayPort
1 x HDMI
1 x LAN (RJ45) 連接埠
1 x 光纖 S/PDIF 輸出
5 x 音訊插孔
4 x USB 3.2 Gen 1 (up to 5Gbps) ports
3 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A + USB Type-C™)
ASUS Wi-Fi module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v5.0)

2 x USB 2.0 接頭支援額外的 4 USB 2.0 連接埠
8 x SATA 6Gb/s 接頭
1 x CPU 風扇接頭
3 x 機殼風扇接頭
1 x 24-pin EATX 電源接頭
1 x 8-pin ATX 12V 電源接頭
2 x Aura RGB Strip Header(s)
1 x 4-pin ATX 12V 電源接頭
1 x Addressable Gen 2 header(s)
1 x 前面板音訊接頭 (AAFP)
1 x 系統面板
1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)
1 x SPI TPM header
1 x Clear CMOS 跳線
1 x CPU OPT Fan connector(s)
1 x AIO_PUMP connector
1 x COM port header
1 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports

使用者手冊
I/O 擋板
2 x Serial ATA 6.0Gb/s 纜線
1 x TUF Certification 卡
1 x M.2 Screw Package
1 x Supporting DVD
1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)
1 x TUF GAMING Sticker

256Mb 快閃記憶體 ROM、UEFI AMI BIOS、PnP、SM BIOS 3.2、ACPI 6.2、多重語言 BIOS, ASUS EZ Flash 3、CrashFree BIOS 3、F6 Qfan 控制、F3 我的最愛、F4 AURA 開/關、最後修改記錄、F9 搜尋、F12 PrintScreen 及 ASUS DRAM SPD (Serial Presence Detect) 記憶體資訊

WOL by PME, PXE

Windows® 10 64-bit

ATX 主機板尺寸
12.0 吋 x 9.6 吋 ( 30.5 公分 x 24.4 公分 )
