AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics 處理器

*有關支援的 CPU 型號資訊，請參閱 tw.asus.com 網站內容。
* Due to CPU limitation, CPU cores supported varies by processors.

AMD X570

4 x DIMM, 最高可支援到128GB, DDR4 MHz 無緩衝區 記憶體
3rd Gen AMD Ryzen™ Processors
雙通道 記憶體架構
*有關記憶體合格廠商清單（QVL）的相關資訊，請參閱 www.asus.com 網站或本使用手冊。
ECC Memory (ECC mode) support varies by CPU.
* The maximum memory capacity supported vary depending on the CPU you installed.
2nd Gen AMD Ryzen™ Processors
4 x DIMM, Max. 128GB, DDR4 MHz 無緩衝區 Memory
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
4 x DIMM, Max. 128GB, DDR4 MHz Memory

Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
支援 VGA 輸出 : HDMI 連接埠
– Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz

3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
Supports AMD 2-Way CrossFireX™ Technology

3rd Gen AMD Ryzen™ Processors
1 x PCIe 4.0 x16 (x16 mode)
3 x PCIe 4.0 x1
2nd Gen AMD Ryzen™ Processors
1 x PCIe 3.0 x16 (x16 mode)
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
1 x PCIe 3.0 x16 (x8 mode)
AMD X570 chipset
1 x PCIe 4.0 x16 (max at x4 mode)

3rd Gen AMD Ryzen™ Processors :
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
AMD X570 chipset :
1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
6 x SATA 6Gb/s埠
支援Raid 0, 1, 10

Realtek® RTL8111H
ASUS LAN Guard

Realtek® S1200A 8 通道 高傳真音效 CODEC *
– 支援 : 插頭偵測, 前面板插孔指定功能
– Front panel audio connector (AAFP)
Audio Feature :
– Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
– Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
– Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
* Choose the chassis with HD audio module in front panel to support 8-channel audio output.

3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
2 x USB 3.2 Gen 2 連接埠 (2 位於背板, teal blue, Type-A *)
3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
2 x USB 3.2 Gen 1 連接埠 (2 位於背板, 藍色, Type-A)
AMD X570 chipset :
2 x USB 3.2 Gen 2 連接埠 (2 位於背板, teal blue, Type-A)
AMD X570 chipset :
4 x USB 3.2 Gen 1 連接埠 (4 位於主機板中)
AMD X570 chipset :
5 x USB 2.0 連接埠 (2 位於背板, , 3 位於主機板中)
* The USB ports under the LAN port can run at USB 3.2 Gen 2 speeds with 3rd Gen AMD Ryzen™ Processors

華碩 EPU :
– EPU
ASUS 5X Protection III :
– ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
– ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
– ASUS Overvoltage Protection: World-class circuit-protecting power design
– ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
– ASUS DIGI+ VRM – Digital power design with Dr. MOS
– ASUS Enhanced DRAM Overcurrent Protection – Short circuit damage prevention
– ASUS ESD Guards – Enhanced ESD protection
ASUS SafeSlot – Protect your graphics card Investment
華碩獨家功能 :
– AI Suite 3
– Ai Charger
– Armoury Crate
ASUS OptiMem：
– Improved DDR4 Stability
華碩靜音散熱解決方案 :
– Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan and PCH Heatsink
– ASUS Fan Xpert 4
華碩 EZ DIY :
– 華碩 CrashFree BIOS 3
– 華碩 EZ Flash 3
– ASUS UEFI BIOS EZ Mode
華碩 Q-Design :
– 華碩 Q-Slot
– 華碩 Q-DIMM
AURA :
– Aura RGB Strip Headers
– Aura Control
– Addressable Gen 2 Header

1 x PS/2 鍵盤/滑鼠連接埠
1 x HDMI
1 x LAN (RJ45) 連接埠
3 x 音訊插孔
2 x USB 2.0
2 x USB 3.2 Gen 1 (up to 5Gbps) ports Type-A
4 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A *)
* The USB ports under the LAN port can run at USB 3.2 Gen 2 speeds with 3rd Gen AMD Ryzen™ Processors

2 x USB 2.0 接頭支援額外的 5 USB 2.0 連接埠
1 x COM 接頭連接埠
6 x SATA 6Gb/s 接頭
1 x CPU 風扇接頭 (1 x 4 -pin)
3 x 機殼風扇接頭 (3 x 4 -pin)
1 x S/PDIF 輸出接頭
2 x Aura RGB Strip Headers
1 x 24-pin EATX 電源接頭
1 x 8-pin ATX 12V 電源接頭
1 x 4-pin ATX 12V 電源接頭
1 x Addressable Gen 2 header(s)
1 x 前面板音訊接頭 (AAFP)
1 x 系統面板
1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)
1 x SPI TPM header
1 x Clear CMOS 跳線
1 x PCH_FAN (1 x 4 -pin)
1 x AIO_PUMP connector (1 x 4 -pin)
2 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports

使用者手冊
I/O 擋板
2 x Serial ATA 6.0Gb/s 纜線
1 x M.2 Screw Package
1 x Supporting DVD
1 x Extension cable for Addressable LED

256 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, F4 AURA ON/OFF, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information

WOL by PME, PXE

Windows® 10 64-bit

ATX 主機板尺寸
12.0 吋 x 9.6 吋 ( 30.5 公分 x 24.4 公分 )
