AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
* 有關支援的 CPU 型號資訊，請參閱www.asus.com 網站內容。

AMD X570

3rd Gen AMD Ryzen™ Processors
4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2933 /2800/2666/2400/2133 MHz Memory
2nd Gen AMD Ryzen™ Processors
4 x DIMM, Max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 MHz Memory
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
4 x DIMM, Max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 MHz Memory
雙通道 Memory Architecture
ECC Memory (ECC mode) support varies by CPU.
* 有關記憶體合格廠商清單（QVL）的相關資訊，請參閱 www.asus.com 網站或本使用手冊。

3rd and 2nd Gen AMD Ryzen™ Processors
Supports NVIDIA® 2-Way SLI® Technology
支援 AMD 3-Way CrossFireX™ Technology
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
Supports AMD 2-Way CrossFireX™ Technology

3rd Gen AMD Ryzen™ Processors
2 x PCIe 4.0 x16 (x16 or dual x8)
2nd Gen AMD Ryzen™ Processors
2 x PCIe 3.0 x16 (x16 or dual x8)
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
1 x PCIe 3.0 x16 (x8 mode)
AMD X570 chipset
1 x PCIe 4.0 x16 (x4 mode)
1 x PCIe 4.0 x1

3rd Gen AMD Ryzen™ Processors :
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
AMD X570 chipset :
1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
8 x SATA 6Gb/s port(s),
Support Raid 0, 1, 10

Intel® I211-AT
Aquantia AQC111C 5G LAN
ASUS LAN Guard
ROG GameFirst V Technology

Intel® Wi-Fi 6 AX200
Supports channel bandwidth: HT20/HT40/HT80/HT160
2 x 2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) with MU-MIMO supports dual frequency band 2.4/5GHz
Up to 2.4Gbps transfer speed

Bluetooth® 5.0

ROG SupremeFX 8通道 高傳真音效 CODEC
– 支援 : Multi-streaming, Front Panel Jack-retasking
– High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
– SupremeFX Shielding Technology
– ESS® ES9023P
– Supports up to 32-Bit/192kHz playback *
Audio Feature :
– Gold-plated jacks
– Optical S/PDIF out port(s) at back panel
– Sonic Radar III
– Sonic Studio III + Sonic Studio Link
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.

3rd Gen AMD Ryzen™ Processors :
4 x USB 3.2 Gen 2 port(s) (4 at back panel, red, Type-A)
2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
4 x USB 3.2 Gen 1 port(s) (4 at back panel, red, Type-A)
AMD X570 chipset :
1 x USB 3.2 Gen 2 front panel connector port(s)
AMD X570 chipset :
4 x USB 3.2 Gen 2 port(s) (3 at back panel, red, Type-A, 1 x Type-C)
AMD X570 chipset :
8 x USB 3.2 Gen 1 port(s) (4 at back panel, blue, 4 at mid-board)
AMD X570 chipset :
4 x USB 2.0 port(s)

ROG RGB Armor
Start Button
Reset Button
ROG Aura
– Aura Lighting Control
– Aura RGB Strip Headers
Extreme Engine Digi+ :
– IR3555 PoweIRstage®
– MicroFine Alloy Chokes
– 10K Black Metallic Capacitors
ROG Extreme OC kit :
– Safe Boot button
– Slow Mode
– LN2 Mode
UEFI BIOS features :
– Tweakers’ Paradise
– ROG SSD Secure Erase
– Graphic Card Information Preview
USB BIOS FlashBack™
Crosschill EK III
ROG Patented Pre-mounted I/O Shield
ROG Exclusive Software
– Mem Tweakit
– RAMCache III
– RAMDisk
– CPU-Z
– GameFirst V
– Sonic Studio III + Sonic Studio Link
– Sonic Radar III
– Overwolf

ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 :
– 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Expert 4, and Turbo App
Gamer’s Guardian:
– DRAM Overcurrent Protection
– 10K Black Metallic Capacitors
– ESD Guards on LAN, Audio,and USB ports
華碩獨家功能 :
– USB BIOS FlashBack™
– AI Suite 3
– Ai Charger
– ASUS CrashFree BIOS 3
– Armoury Crate
– Pre-mounted I/O Shield
– ASUS NODE: hardware control interface
– BIOS FlashBack™ Button
– Clear CMOS Button
ASUS SafeSlot – Protect your graphics card Investment
LiveDash OLED
AURA :
– Aura Lighting Control
– Aura RGB Strip Headers
– Addressable Gen 2 Header
ASUS Q-Design :
– ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
– ASUS Q-DIMM
– ASUS Q-Connector

1 x 光纖 S/PDIF 輸出
1 x Clear CMOS button(s)
1 x USB BIOS FlashBack™ Button(s)
1 x ASUS Wi-Fi Module
1 x Gold-plated audio jacks
4 x USB 3.2 Gen 1 (up to 5Gbps) ports
8 x USB 3.2 Gen 2 (up to 10Gbps) ports ()
Anti-surge LAN (RJ45) port
1 x AQC-111C 5G LAN port

2 x USB 2.0 接頭支援額外的 4 USB 2.0 連接埠
1 x PCH_FAN
8 x SATA 6Gb/s 接頭
1 x CPU 風扇接頭
3 x 機殼風扇接頭
1 x Optional Fan 接頭
1 x 24-pin EATX 電源接頭
2 x Aura RGB Strip Header(s)
1 x 8-pin ATX 12V 電源接頭
1 x 4-pin ATX 12V 電源接頭
2 x Addressable Gen 2 header(s)
1 x 前面板音訊接頭 (AAFP)
1 x M.2 Socket 3 with M key, type 2242/2260 storage devices support (both SATA & PCIE mode)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & PCIE mode)
1 x CPU OPT Fan connector(s)
1 x AIO_PUMP connector
1 x H_AMP fan connector
1 x W_PUMP+ connector
1 x Slow Mode switch(es)
1 x LN2 Mode header(s)
1 x Power-on button(s)
1 x Reset button(s)
1 x Node Connector(s)
1 x Safe Boot button
1 x ReTry button
1 x System panel connector
1 x W_IN header
1 x W_OUT header
1 x W_FLOW header
1 x Thermal sensor connector
1 x Speaker connector
1 x USB 3.2 Gen 2 (up to 10Gbps) connector
2 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 4 USB ports

使用者手冊
1 x ROG logo plate sticker
4 x SATA power cable
1 x M.2 Screw Package
1 x Supporting DVD
1 x ROG big sticker
1 x Q-Connector
1 x Wi-Fi Antenna(s)
1 x Extension Cable for RGB strips (80 cm)
1 x Extension cable for Addressable LED
1 x ROG coaster(s)
2 x ROG weave SATA 6G cable
1 x ROG Thank you card

256 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.2, ACPI 6.2

WOL, PXE

Windows® 10 64-bit

ATX 主機板尺寸
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
