- 作業系統
Windows 10 Pro for Workstations
Windows 10 Home – ASUS 推薦商務用 Windows 10 Pro。
Windows 10 Pro – ASUS 推薦商務用 Windows 10 Pro。
- 中央處理器
1 x Socket LGA1200
The 10th generation Intel® Core™ i9/i7/i5/i3 processors
Intel® Xeon® W-1200 Processors
- 核心晶片組
Intel® W480 Chipset
- 記憶體
總 Slots 數 : 4 (2 通道)
總容量 : 最大至 128GB UDIMM
記憶體類型 :
雙通道 DDR4 2933/2666 non ECC and with ECC
記憶體大小:
32GB, 16GB, 8GB UDIMM
* 最新更新請參考支援頁面。
- 擴充槽
Total: 6
Location-1: PCIe x1 slots (Gen3 x1 link, FH, FL)*
Location-2: PCIe x16 slots (Gen3 x16/x8 link, FH, FL)
Location-3: PCIe x1 slots (Gen3 x1 link, FH, FL)*
Location-4: PCIe x16 slots (Gen3 x0/x8 link, FH, FL)
Location-6: PCIe x16 slots (Gen3 x4 link, FH, FL)
Location-7: PCIe x16 slots (Gen3 x4 link, FH, FL)**
*the bandwidth of PCIe link is shared with M.2_1
** the bandwidth of PCIe link is shared with 4 x SATA ports
- 資料儲存應用
SATA 控制器: Intel® W480 Chipset
8 x SATA3 6Gb/s 連接埠
Intel® Rapid Storage Technology(RST) (For Windows Only)
(Support Software RAID 0, 1, 5, 10 )
- 磁碟機插槽
1x internal 2.5” drive bay
3x internal 3.5” drive bay (or 3x internal 2.5” drive bay: optional cage required)
2x internal 2.5”/3.5” drive bay (optional cage required)
- 附屬儲存裝置 FDD/CD/DVD
2 x 5.25″ media bays
(Options: No ODD/DVD-RW)
- 網路功能
1 x I225-LM
1 x i219-LM
- 前面板輸出端子
2 x USB 3.2 Gen1
2 x USB 2.0
1 x Headphone port
1 x Microphone port
- Rear I/O Ports
2 x USB 3.2 Gen2 ports (1 port at Type A, 1 port at Type C)
4 x USB 3.2 Gen1 ports
1 x HDMI
1 x DisplayPort
1 x DVI-D
1 x VGA
2 x RJ-45 ports
1 x 7.1-channel Audio I/O ports (5 + 1 Audio jacks)
- 作業系統支援
Windows® 10 64-bit
- 管理工具
ASUS Control Center Enterprise (Optional)
- Regulatory Compliance
BSMI, CE, FCC(Class B), Energy Star
- 產品尺寸
423mm x 190mm x 435mm
16.65″ x 7.48″ x 17.13
- 主機板尺寸
Tower
- 重量
Net Weight : 9.9 KG
Gross Weight : 12.1 KG
- 電源規格
300W 80PLUS Single Power Supply, Bronze
Rating:100-127/220-240V, 6/3A, 60-50Hz, Class I
500W 80PLUS Single Power Supply, Gold
Rating:100-240Vac, 50/60 Hz, 7-3.5A
700W 80PLUS Single Power Supply, Gold
Rating:100-240Vac, 10-5A, 50/60Hz
450W/550W/750W 80PLUS Single Power Supply, Gold
Rating: 100-240Vac,50-60 Hz,9-4.5A
- 運作環境
Operation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
- Accessory Box
1 x Pro E500 G6 Support CD
1 x Windows 10 Professional 32/64bit Recovery DVD (for OS bundled SKU)
1 x AC Power Cable
1 x COM port Cable
1 x VGA Support CD
- 選購配件
Smart Card Reader
Anti-Virus CD pack
OS
DVD-ROM
Keyboard and mouse
Print port cable
- 備註
*1 PCIe Bandwidth is shared between M.2 socket and PCIex1.
SATA Bandwidth is shared between M.2 socket and SATA port.
*MEMORY:
DDR4 2933 speed is supported by intel POR (Plan on Record).
DDR4 3200 speed is compatible but need to be limited to 2933 in BIOS.
*Intel® vPro™ support
