Description
|
Max. Capacity Used
information_stroke
|
100 % |
|---|---|
| Main Input Voltage | 230 V |
| rated power in W | 390 W |
| rated power in VA | 650 VA |
| nb of power socket outlets | 6 IEC 60320 C13 |
| battery type | Lead-acid battery |
| provided equipment | User manual USB cable |
|---|---|
| Number of power module free slots | 0 |
| Number of power module filled slots | 0 |
| redundant | No |
| height | 19 cm |
|---|---|
| width | 9.1 cm |
| depth | 31 cm |
| net weight | 6.4 kg |
| mounting preference | No preference |
| mounting mode | Not rack-mountable |
| two post mountable | 0 |
| USB compatible | No |
| network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
|---|---|
| input voltage limits | 176…294 V |
| maximum input current | 10 A |
| switching current capacity | 10 A |
| Maximum configurable power in W | 390 W |
|---|---|
| output frequency | 50/60 Hz +/- 1 Hz sync to mains |
| UPS type | Line interactive |
| Waveform Type | Stepped approximation to a sinewave |
| Maximum configurable power in VA | 650 VA |
| Transfer time | 10 ms typical : 12 ms maximum |
| product certifications | A-Tick C-Tick CE EAC RCM TISI |
|---|---|
| marking | GS Mark |
| ambient air temperature for operation | 0…40 °C |
|---|---|
| relative humidity | 0…95 % |
| operating altitude | 0…10000 ft |
| ambient air temperature for storage | -15…45 °C |
| storage Relative Humidity | 0…95 % |
| storage altitude | 0.00…15240.00 m |
| acoustic level | 45 dBA |
| heat dissipation | 13.3 Btu/h |
| Run Time | View Runtime Graph
action_new_window
|
|---|---|
| Efficiency | View Efficiency Graph
action_new_window
|
| number of battery filled slots | 0 |
| number of battery free slots | 0 |
| Battery recharge time | 12 h |
| number of battery replacement quantity | 1 |
| battery voltage | 12 V |
| battery capacity | 7.0 Ah |
| battery charger power | 6 W rated |
| Battery power in VAH | 75 VAh runtime |
| battery life | 3…5 year(s) |
| extended runtime | 0 |
| control panel | Multifunction LCD status and control console |
|---|---|
| alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| noise suppression | Full time multi-pole noise filtering : 10% of IEEE surge let-through : zero clamping response time: instantaneous |
|---|---|
| Data line protection | RJ45 network line – 10/100/1000 Base-T Ethernet |
| Package 1 Weight | 7.4 kg |
|---|---|
| Package 1 Height | 25.5 cm |
| Package 1 width | 44 cm |
| Package 1 Length | 14.3 cm |
| SCC14 | 10731304346934 |
| Number of Units in Package 2 | 2 |
| Package 2 Weight | 15.65 kg |
| Package 2 Height | 228.60 mm |
| Package 2 width | 457.20 mm |
| Package 2 Length | 279.40 mm |
| Warranty | 2 years repair or replace, 3 years repair or replace for European Union countries |
|---|
